OptiGlow Specifications
OptiGlow Plasma System is ideal for
- Contact Lens
- Optical components
- Medical devices
- Plastic & Ceramics
Testing and Samples
Glow Research will run samples on a contract basis or for clients interested in the eventual purchase of a new or rebuilt system. Contact us for more information.Contact Us
Address:
12014 S. 35th Ct.
Phoenix, Az. 85044
United StatesPhone:
480-621-8405Translator
Translator
OptiGlow Specifications
Zinc-coated steel, polyurethane painted.
System houses process chamber, RF generator, electronics & controls.
Vacuum pump & gas control flowmeter
Dimensions (Door Closed):
13.75″ W x 13.5″H x 19.5″L. (349.25 mm W x 342.9 mm H x 495.29 mm L)
Weight (with Vacuum Pump):
75 lbs. (34.1 kg)
Chamber:
4.25″ (ID) Diameter x 6″ (ID) Deep (107.94 mm x 152.39 mm)
High Grade 6061-T Aluminum
RF Power:
100 kHz
50 Watts, solid state
Automatic impedance matching
Control:
Push-button interface, timer endpoint control and pressure read-out display
Pump System (included in system cabinet):
6 CFM wet pump with oil mist eliminator
Facilities Requirements:
Power:
120-220 VAC, single phase,
10A, 50-60 Hz, 18 AWG, 3 wire (preset for International or US standards)
Process Gas (ea):
Room air – primarily made up of nitrogen (78.09%) and oxygen (20.95%).
